The Manrose WF230A is a 230mm (9") commercial-grade axial extractor fan designed for high-performance ventilation in environments like kitchens, utility rooms, offices, and shops.
It is primarily a window-mounted unit but can be wall-mounted using an optional fixing kit.
Key Product Features
Automatic Thermo-Activated Shutters: These internal back-draught shutters open silently approximately 45 seconds after the fan is switched on, preventing heat loss and drafts when the fan is inactive.
High Extraction Capacity: It delivers an extraction rate of 668 m³/hr (185 litres per second), making it suitable for demanding commercial and domestic spaces.
Durable Construction: Built from high-impact ABS thermoplastics for strength, durability, and easy cleaning.
Quiet Operation: Operates at a sound level of approximately 50 dB(A) at 3 metres.
Safety & Compliance: Rated IP44 for water resistance and compliant with UK Building Regulations on Ventilation (Part F1).
Technical Specifications
Impeller Diameter 230 mm (9 inches)
Power Consumption 41 Watts
Voltage 220-240V AC, 50Hz
Dimensions 286mm (W) x 286mm (H) x 141mm (D)
Installation Hole Standard 260mm diameter hole for window mounting
Max Temperature 40°C
| Mounting | Window or Wall |
| Size | 9" |
| Brand | Manrose |
