Liveelec CB120D
MCB SP D Curve 20A 10kA (CB120D)

The Live Electrical CB120D is a 1-pole (single-pole), 20A miniature circuit breaker (MCB) with a D-curve tripping characteristic and a 10kA breaking capacity.
Designed for 230/400V AC, it is ideal for protecting circuits with high inrush currents, such as motors and lighting.
It features IP20 protection and 35mm DIN rail mounting.

Key Features and Specifications:
Type: Live Electrical Single Pole MCB (CB120D)
Current Rating: 20A
Tripping Curve: D (suitable for high inrush loads)
Breaking Capacity: 10kA (10,000A)
Voltage: 230/400V AC, 50/60Hz
Mounting: 35mm DIN rail
Terminal Capacity: Up to 16mm²
Electrical Life: 8,000 cycles
Protection Rating: IP20
Dimensions: 1 Module wide

Applications:
Motor starting
Lighting circuits with high surge currents
Industrial or commercial applications requiring Type D protection

The unit is compatible with Live Electrical consumer units and offers both overload and short-circuit protection.
